Overview of Hymu80

HyMu 80 alloy is an unoriented, 80% nickel-iron-molybdenum alloy which offers extremely high initial permeability as well as maximum permeability with minimum hysteresis loss.

HyMu 80 alloy has been used primarily in transformer cores, tape wound toroids and laminations where compactness and weight factors are important. It has also been used for shielding to protect electrical components from stray magnetic fields.

Overview of NETIC®

NETIC® is uniquely different from Co-NETIC®. It is an iron alloy that is often applied in fields of high intensity (strong fields) because of its high magnetic saturation characteristics. Frequently, NETIC® is used in conjunction with a layer of Co-NETIC® as layering is proven to provide extra precaution and/or lower risk of electro-magnetic interference. If used in combination, the NETIC® layer is placed closest to the source of interference, with Co-NETIC® or MuMETAL® layer closest to the component being shielded.

Co-NETIC® Or NETIC®?

In fields of low intensity, Co-NETIC® is used in order to utilize its high initial permeability and corresponding high attenuation characteristics. In strong fields of high intensity, NETIC® is preferred because of its high magnetic saturation characteristics. In some applications, combinations of the two materials may be useful, with NETIC® material always placed closer to the source of magnetic interference.

Overview of Co-NETIC®

Co-NETIC® is considered far superior in shielding performance due to its consistent quality, material composition and Perfection Annealing process. A Ferromagnetic that is used primarily in low intensity fields where high attenuation is desired (high initial permeability & high shielding efficiency), it has become our leading brand. Co-NETIC® alloy is readily available from stock in three forms:

Co-NETIC® AA Perfection Annealed
Co-NETIC® Stress Annealed
Co-NETIC® B Stress Annealed

Overview of Heavy Metal Tungsten Alloy (ASTM B 777)

Heavy metal alloys are pseudo-alloys of tungsten with a nickel-iron or nickel-copper matrix. They are produced by powder metal and sintering processes. Tungsten Heavy Alloys has a high density of 17-19 g/cm³. Comparable densities are only reached by gold or platinum. These alloys are used as mass balancing weights and attenuators in aircraft construction, in motors and power trains, as oscillating weights and centrifugal weights in machines and in equipment construction, and in medical technology for both protection from and focusing of ionizing radiation in x-ray and measuring devices.

Overview of MuMETAL

For decades, scientists, engineers, metal suppliers and fabricators have referred to mumetal as the industry standard. However, MuMETAL® is a registered trade name and exclusively available from Magnetic Shield Corporation, a worldwide leader in low-frequency magnetic shielding.

Overview of Molybdenum TZM

Molybdenum TZM is an established Molybdenum alloy (0.50 Ti, 0.08 Zr, balance Mo), which is consolidated by either the P/M or vacuum arc-casting processes. It gives excellent service in applications that require high strength and creep resistance at elevated temperatures. TZM Molybdenum Alloy also permits higher service temperatures without softening or weakening.

Overview of Titanium 6Al/4V

Ti-6Al-4V (UNS designation R56400), also sometimes called TC4,[1] is an alpha-beta titanium alloy with a high strength-to-weight ratio and excellent corrosion resistance. It is one of the most commonly used titanium alloys and is applied in a wide range of applications where low density and excellent corrosion resistance are necessary such as e.g. aerospace industry and biomechanical applications (implants and prostheses).

Overview of Zirconium

Zirconium is mainly used as a refractory and opacifier, although small amounts are used as an alloying agent for its strong resistance to corrosion. Zirconium alloys can be found in pipes, fittings and heat exchangers, catalytic converters, furnace bricks, lab crucibles, surgical instruments, television glass, removing residual gases from vacuum tubes

Overview of Tantalum

Like Niobium, Tantalum is a heat-tolerant refractory metal with excellent corrosion resistance. Often alloyed with other metals, tantalum is used to make super alloys used in chemical processing, jet engines and nuclear reactors. Its oxidation properties also make it an excellent choice for many electronic applications, including electrolytic capacitors and high-power resistors. Tantalum is also highly bio-compatible and used extensively for medical applications, such as skull plates, hip joints, suture clips and stents.

Overview of Niobium

Niobium (also known as columbium) is a shiny, ductile metal primarily used in alloys. It improves the properties of steel and is often used in gas pipelines, jet engines and structural applications. Because of its corrosion resistance and ability to perform at high temperatures, niobium metal plates, rods and sheets are used in sputtering targets and chemical processing equipment. At extremely low temperatures, it becomes superconductive. Superconductive niobium wire is used to make extremely powerful electromagnets used in magnetic resonance imagery and particle accelerators.

Overview of Tungsten

Tungsten has the highest melting point of all metals and, at temperatures greater than 1650°C, the highest tensile strength. Its thermal expansion rate is similar to that of borosilicate glass and silicon. Tungsten’s good thermal and electrical conductivity make it an excellent choice for microprocessor applications. It is also used in electron emitters, heater coils, cathode ray tubes, electrical contacts and a variety of high-heat applications.

Overview of Molybdenum

Molybdenum is a plentiful, cost-effective metal known for its strength and stability in high-heat applications. Softer and more ductile than tungsten, it is often alloyed with other compounds to improve corrosion resistance and strength at high temperatures.

Overview of Titanium CP Grades 1 & 2

Unalloyed Commercially Pure (CP) Titanium is available in four different grades, 1, 2, 3 and 4, which are used based on the corrosion resistance, ductility and strength requirements of the specific application. Titanium Grade 2 is stronger than Grade 1 and equally corrosion-resistant against most applications.

Overview of Constantan

Constantan is a copper-nickel alloy used in a variety of thermocouple applications. It is paired with iron, copper and Chromel® to form types J, T and E thermocouples, respectively. Known for its high electrical resistivity and its ability to perform consistently despite changes in temperature, Constantan is also widely used throughout the electronics industry.

Overview of Chromel®

Used with Alumel® in type K thermocouples and with Constantan in type E thermocouples, Chromel® is made of nickel and chromium.

Overview of Alumel®

Used in conjunction with Chromel® in type K thermocouples, Alumel®1 is made of nickel, manganese, aluminum and silicon.

Overview of 200 Series Nickel

200 Series are chromium-manganese-nickel alloys, which maximize the use of manganese and nitrogen to minimize the use of nickel. 200 Series Nickel has good mechanical properties and excellent corrosion resistance to alkalis. It also has good electrical, thermal and magneto-strictive properties.

Overview of Invar® 36

With an extremely low coefficient of thermal expansion, approximately one-tenth that of carbon steel at temperatures up to 400° F, Invar® is often thought of as the material of choice for low expansion nickel alloy applications. The ability to maintain strength at very low temperatures also makes it the optimum choice for containing some liquid gasses.

Overview of Alloy 52

Alloy 52 is a nickel-iron alloy with a thermal expansion rate similar to soft glasses and ceramics. Typical applications include voltage regulators, conductors, and glass-to-metal hermetic seals.

Overview of Kovar®

Composed of iron, nickel and cobalt, Kovar®1 has thermal expansion characteristics similar to hard glass, making it an excellent choice for glass-to-metal hermetic seals. Kovar® is widely used in the electronics industry.
